Core advantages of CDIP
Extreme temperature resistance: The ceramic substrate (alumina) can withstand a temperature range of-55ยฐC to +175ยฐC, suitable for high temperature welding processes (wave soldering) and harsh environments.
Excellent air tightness: using glass or metal sealing technology, the leakage rate is less than 5 x 10โปโธ ATMยทCCยณ/SEC, in line with MIL-STD-883 standard, effectively moisture-proof and oxidation-proof, and prolong the life of devices.
Anti-mechanical impact: The ceramic structure has high strength and better seismic performance than plastic DIP (PDIP), which is suitable for high vibration scenarios (aerospace equipment).
Low dielectric loss: The dielectric constant of alumina ceramic (~9.8) is suitable for medium and high frequency circuit design to reduce signal attenuation.
Electromagnetic shielding capability: the metallized layer can suppress electromagnetic interference (EMI) and improve signal integrity.
Chemical corrosion resistance: acid and alkali resistant, salt spray corrosion resistant, suitable for chemical industry, Marine and other harsh environment (oil drilling sensors).
Radiation resistance: special doping process can improve radiation resistance, used in satellite and nuclear industry electronic devices.
Temperature range: military grade-55ยฐC to +175ยฐC, civil grade-40ยฐC to +125ยฐC.
Thermal resistance (ฮJA): Typical value 35-50ยฐC/W, supports medium power chip heat dissipation requirements.
Pin count and spacing: standard pin count 8-64, spacing 2.54MM, compatible with traditional through-hole technology (THT).
Size and weight: The typical 14-pin package size is about 19MMร6.35MM, light but strong structure.
Air tightness test: helium mass spectrometry leak detection and pressure cooker test (PCT) to ensure long-term sealing.
Life prediction: The average trouble-free time (MTBF) is calculated by ARRHENIUS model to be over 100,000 hours.
Missile navigation system: withstand the high temperature impact and violent vibration at the moment of launch.
Satellite power management module: radiation resistant ceramic to ensure long-term stable operation in space environment.
Downhole sensors: continuously monitor oil and gas parameters in high temperature and high pressure environment above 150ยฐC.
Power electronic protection circuit: used for high voltage relay control module, arc and temperature fluctuation resistant.
Implantable medical devices: pacemakers require high sealing to ensure more than 30 years of trouble-free operation.
Laboratory instruments: chemical corrosion resistant properties suitable for sensor packaging in precision analytical equipment.
Aluminum nitride ceramic replacement: thermal conductivity increased to 170 W/MK, reducing thermal resistance (target <20ยฐC/W), suitable for high power chips.
Low cost sintering process: improve ceramic forming technology (lamination forming), reduce the cost of small and medium batch production.
Embedded passive components: resistors and capacitors are integrated through LTCC (low temperature co-fired ceramic) technology to simplify peripheral circuits.
Intelligent sensor fusion: temperature and pressure sensors are integrated in the package to realize self-monitoring function (industrial equipment health diagnosis).
Nuclear electronic equipment: development of neutron radiation resistant doped ceramics for nuclear reactor control modules.
Deep-sea exploration equipment: high-pressure packaging design (>1000 atmospheric pressure) and electronic system integration, supporting deep-sea robot applications.
Recyclable ceramic materials: develop environmentally friendly ceramic recipes to reduce carbon emissions in the manufacturing process.
Lead-free welding process: replace traditional lead-containing solder and comply with global environmental regulations (ROHS).
According to TECHINSIGHTS data, the global ceramic DIP packaging market size in 2023 is about $850M. It is expected that:
$1.1 billion in 2025 (CAGR 8.7%)
Breakthrough of $1.8 billion (CAGR 10.2%) by 2030
Growth drivers:
CDIP continues to hold a significant position in the field of extreme environment electronics due to its irreplaceable reliability. Despite competition from surface mount technology (QFP, BGA), CDIP will continue to thrive in high-reliability scenarios through material innovations (aluminum nitride), functional integration (LTCC), and expansion into emerging fields (nuclear energy, deep-sea exploration). It will become a key packaging choice for military, energy, and medical equipment. Future development will focus on high performance, multifunctionality, and environmental compatibility, solidifying its position in the high-value-added market.
